About Challenge



As the COVID-19 pandemic disrupted the normal course of life and business, it also exposed many opportunities for the industry to innovate and build stronger enterprises going forward.

In the Built Environment sector, there is a need to accelerate the adoption of advanced building technologies to allow for cleaner, higher quality construction that is less manpower intensive. Emerging technology trends such as robotics and artificial intelligence will play an instrumental role in reshaping the Built Environment sector in a post COVID-19 world.

The Built Environment Accelerate to Market Programme (BEAMP) is a multi-agency initiative designed to build a vibrant innovation ecosystem for the Built Environment sector.

Since its inaugural launch last year and over two iterations, BEAMP has created a platform where innovators and Built Environment industry players come together to collaborate and solve key challenges through accelerated product and market development.

BEAMP returns this year to discover new solutions and expand on the Built Environment sector’s potential for disruptive innovation. If you have an innovative solution that can aid the transformation of the sector, this is an opportunity for you to receive test-bedding opportunities with industry players, be mentored by experts, and also secure a funded pilot!

Learn More
Challenge Owner(s)Santarli
Industry Types(s)
Construction, Electronics, ICT and Media

Santarli

Tower cranes are heavily deployed on large-scale construction sites to lift construction materials. The efficiency of the tower crane usage largely depends on the ability of the site management and lifting supervisors to plan the lifting schedule and coordinate lifting works.

Ideally, the lifting schedule should consider the various trades and subcontractors on-site and be optimised based on key factors, such as the urgency of work, delivery of materials, and availability of work areas. Currently, lifting supervisors decide on what needs to be prioritised or delayed. This decision is subject to the individual’s judgment. Due to unforeseen site circumstances, such as poor weather, the lifting schedule often needs to be quickly adapted to minimise impact to the site progress.

Opportunities Areas and Key Challenges

The lifting schedule of the tower crane can be better planned by introducing a shared digital platform for the site contractors to facilitate the scheduling of lifting assignments. Site contractors can input their lifting requirements into the digital platform, and the platform would weigh the different factors of consideration to generate an optimal and unbiased schedule. Site management should be able to review the schedule before execution. The generated schedule should be adaptable to changes to contractor requirements and site conditions, such as poor weather. Site contractors should also have the flexibility to make adjustments according to their requests.

Sensors and IoTs can be incorporated into the leased tower crane in a non-invasive manner, in order to automatically collect and track data on the lifting operations. This offers visibility of site progress: for example, whether the lifting schedule is on track and which stage of the lifting operation the material is currently at. The data collected would be channelled into the digital platform to provide accurate and real-time updates to all the affected parties.

For the site management and the organisation’s senior management, the digital platform can provide timely updates on the schedule and full visibility of the operations.

Expected Outcomes

The digital platform gathers the lifting requirements of the site contractors and automatically generates an optimal and fair schedule for the tower crane. The digital platform also provides site management with visibility of and control over the tower crane operations.

Download all challenge statements

Learn More

Challenge Owner(s)Chuan Lim Construction
Industry Types(s)
Construction, Electronics, ICT and Media

Chuan Lim Construction

An operator is attached to an excavator throughout his workday. With the help of the foreman and banksman, he gets assigned to tasks that need to be completed with an excavator, and he needs to navigate within the worksite to the specific position to commence work.

Opportunities Areas and Key Challenges

The utilisation and productivity of the excavators on the construction site could be further optimised with the help of technology to monitor the excavator’s activities. This could support intelligent decision making and better deploy the excavators to their assigned positions at the worksite.

Currently, there is limited visibility on the excavator’s activities, and the data needs to be manually collected. In other words, we are interested in monitoring the behaviour of the operator to gain actionable insights on his performance and fitness for work.

We seek a sensor and/or IoT system which enables the real-time collection of data that can be analysed and conveyed to the foreman or site manager to support better planning of work activities. Another possible value-adding opportunity is to estimate the total volume of land excavated - data that can in turn be reported to the client. The proposed solution must be adaptable to various models of excavators to increase the chances of deployment of the solution at scale.

Expected Outcomes

The proposed solution augments existing excavators to support monitoring of its operator and its operations (activities). The data gathered from monitoring the excavator and/or the operator is analysed, visualised and reported to the foreman or site manager for review or further action. Ultimately, the solution improves the productivity of the excavators.

Download all challenge statements

Learn More

Challenge Owner(s)Santarli
Industry Types(s)
Construction, ICT and Media

Santarli

Production metrics comprise data on the actual quantity of work completed daily, as well as the resources and manpower mobilised for the different trades on a construction site. Currently, site supervisors manually record production metrics on paper. They submit the records to site engineers who compile and tabulate the data collected.

This process is tedious, time-consuming and prone to human error. There is also lag time before the generated data is received by the site management and the organisation’s senior management.

Hence, these stakeholders do not have up-to-date information on actual versus planned production metrics, to better track the progress of works, investigate on-site issues, and call for early intervention if necessary.

Opportunities Areas and Key Challenges

A digital solution would assist site supervisors in their daily routine to gather actual production metrics for their site. The existing data collection method is limited by the paper format, and a new digital means would serve to ease the data collection process and allow more data to be collected, such as data specific to individual workers and machinery deployed on-site.

The platform must be able to be installed on the personal devices of site supervisors and act as their personal assistant by giving them timely reminders to submit the production metrics. The submitted production metrics would then be sent to the site engineer or management for review and validation. For reporting purposes, the actual production metrics collected would be compiled, tabulated, visualised and compared against the planned production metrics. A solution with the capabilities to calculate the projected days delayed or ahead would also be useful for site resource planning.

Expected Outcomes

The digital solution supports better data collection of the production metrics and automates the process of compiling, tabulating, visualising and comparing production metrics for same-day reporting to site management and senior management. The solution calculates the projected days delayed or ahead to assist with site resource planning. The solution also reduces human errors.



Download all challenge statements

Learn More

Challenge Owner(s)Building and Construction Authority (BCA)
Industry Types(s)
Construction, Electronics, ICT and Media

Building and Construction Authority (BCA)

A facade is an exterior face of a building comprising materials and connections. In response to ageing buildings and increasingly complex facade designs, a Periodic Facade Inspection (PFI) regime will be made mandatory to facilitate the early detection of facade deterioration and allow defects to be rectified in a timely manner.

Facades can come in many forms, including engineering facades like curtain walls and cladding, and architectural finishes like plaster and tiles. The use of cladding can be seen on commercial, office and industrial developments. Commonly-used materials for claddings are metal, stone and board materials. The fixings or connections of the claddings to the main structural framing are mostly concealed by the facade barrier.

Under the PFI regime, the building owner shall engage a Competent Person (CP) to identify areas of problematic facade and carry out full visual and close-up inspection (i.e. involving physical contact with the facade) of the facade condition. With the conventional close-up inspection method, the inspection process is laborious and time consuming. Currently, the close-up inspection of cladding facade may involve the dismantling of facade panels or the use of a borescope to assess the conditions of the connections. The dismantling and subsequent reinstallation of the cladding panel after inspection and the use of borescope are inefficient and may compromise the safety and performance of the cladding.

Opportunities Areas and Key Challenges

Inspection technologies, such as mmWave and active infrared technologies, could perform the inspection in a non-destructive testing manner and eliminate the need to dismantle facade panels or carry out activities that could affect the structural integrity.

If combined with drones or wall-climbing technologies, we could also omit the usage of height-access equipment. The solution could quickly inspect a large surface to identify cladding panels with a higher risk of failure -- for example, loose panels -- and highlight the risky panels to CP for further investigation. The cameras and inspection technologies would need to be adapted into a form that can be fitted and integrated into the drones or wall-climbing technologies.

Expected Outcomes

The solution streamlines the inspection of the cladding facades, so that a thorough inspection can be done with minimal expense of manpower and time. Ultimately, the solution supports the early detection of facade deterioration, so that the defects are rectified in a timely manner.

Download all challenge statements

Learn More

Challenge Owner(s)Kajima Corporation
Industry Types(s)
Construction, Land Transport, Logistics

Kajima Corporation

After the building structure is completed, materials for finishing works need to be carried from the loading points of each floor to the exact location on that floor where the work takes place. Materials, such as bricks, cement, tiles, and wall panels, come in various shapes and sizes, and have different considerations when being transported.

In order to prevent clutter at the worksites, the materials are collected by workers as required before the start of their work. They typically use manual equipment, such as trolleys and wheelbarrows. The planning for the material collection process is done by the supervisor or the workers themselves. At each site, there are different sub-contractors in charge of different tasks, sharing the sameloading site.

Opportunities Areas and Key Challenges

A robotics solution could support the on-demand delivery of materials that are optimised based on the work progress. The solution would allow subcontractors to focus on their tasks at hand and spend less time collecting materials from the loading point. The robotics solution would ideally be able to carry all types of materials, but as a start, bricks and cement are of higher priority.

The following technical capabilities and specifications would best fit existing needs:

● Capability to navigate the building floor, which includes concrete slab with steps of up to 150mm in height and slopes of up to 1:12 ratio, with minimal human intervention;

● Ability to carry loads up to 500kg;

● Allowance for the full load of materials to easily fit through a normal-sized door;

● Capability to load and unload materials with minimal human intervention;

● Prevention of collision with people or structures; and

● Manual override of the automated functions.

For a digital-enabled and seamless experience, we are also interested in solutions that support the planning and management of material delivery. Supervisors and workers would be able to track the real-time status of the material delivery, such as information on the collected items and schedule. Data-driven planning would reduce work interruptions due to lack of materials.

Such a solution could also help the management of the main contractor and subcontractors to better understand material consumption rates on-site with specific data on material type, time, and location. This would support the replenishing of materials to prevent project delays.

Expected Outcomes

The solution reduces the manpower required to one (or even none) for each trip to replenish materials for the work sites. The material delivery planning and management solution supports supervisors and site managers to minimise interruptions and delays in work by providing them with real-time data on materials and the delivery process.

Download all challenge statements

Learn More

Challenge Owner(s)Penta-Ocean Construction
Industry Types(s)Construction

Penta-Ocean Construction

When carrying out Addition and Alteration (A&A) works to existing buildings, it is important for the contractors to check the actual layout and conditions of the as-built services, such as air conditioning duct, water pipes and electrical trays located in the ceiling space. This information is usually captured in different 2D drawings,and the accuracy of the information needs to be verified on-site as any difference could potentially impact the requirements for A&A works.

The conventional method to check the as-built services concealed in the ceiling space requires the following steps:

  1. Workers use height access equipment that is most suited to the ceiling height. The supervisor or engineer could be present to ensure safety and provide instructions.
  2. Workers would open up a hole in the ceiling. The complexity of this task would differ depending on the ceiling type, for example, gypsum ceiling boards and plasterboards.
  3. Either the worker, supervisor or engineer would visually inspect the ceiling, record the details, and even take pictures for reference. Sometimes, there is a need to climb into the ceiling space for closer inspection. The ceiling would need to be restored to its original condition.

Light Detection and Ranging (LiDAR) technology has been tested to improve step 3. However, significant manpower and time are still being exhausted to perform steps 1, 2 and 4.

Opportunities Areas and Key Challenges

An inspection technology that can capture information on the layout of as-built services with minimal destructive interventions performed to the ceiling would save time and manpower, and improve safety.

The following are the requirements for the solution to be useful:

  • Accurately portray the position and the size of the as-built services;
  • Capture features (for example, material type) that can help to distinguish between different as-built services;
  • Identify useful fixtures or fittings (such as valves); and
  • Complete the scanning and image capturing in an equal or shorter time than the conventional method.



The proposed solution should consider how the inspection would be done at height and over a large area with minimal manpower. Any data captured would also need to be organised and referenced to the location. It is also desirable that the information gathered can support the conversion to a Building Information Modeling (BIM) knowledge base.

Expected Outcomes

The solution provides a way to gather details on the layout of as-built services located in the ceiling space while minimising the need to open up the ceiling and disruption to the room occupants. The solution reduces the time needed to check the as-built services and potentially allows the task to be executed with just one person.

Download all challenge statements

Learn More

Challenge Owner(s)
Admaterials Technologies, Land Transport Authority (LTA)
Industry Types(s)
Construction, Electronics, ICT and Media

Admaterials Technologies, Land Transport Authority (LTA)

Corrosion monitoring is important in Singapore due to high humidity levels and proximity to saltwater bodies. Linear Polarisation Resistance and Open Circuit Potential measurements are the common tests for corrosion monitoring of reinforcing bars (“rebars”) inside concrete structures. Both tests require hacking of the concrete cover surrounding the rebars, so that contact can be made with the rebar to complete a circuit. These concrete covers usually have a thickness of 20mm but can have a thickness of up to 50mm for critical structures. Some structures have exposed wires connected to rebars to ease the process of measurement testing, but this cannot be replicated throughout the entire structure.

The current practice is time consuming and hard to execute, especially when workers have limited access to the site (for example, in the scenario where tunnels and the site are already in operation). The hacking of concrete cover damages the concrete structures and could hasten corrosion rates when the rebar is exposed to air and moisture.

Opportunities Areas and Key Challenges

An inspection or monitoring technology that allows for a non-destructive testing approach towards both the concrete and rebar would improve the corrosion monitoring process by eliminating the need to hack off the concrete cover.

We are open to different measurement techniques, such as impedance or electrical pulse. One way to monitor for corrosion is to study the chlorine penetration and pH level in the concrete layer as well as the condition of the passive film layer surrounding the rebar. Concrete usually has a pH level of 12 and can decrease when chlorine penetrates the concrete and destroys the passive film layer surrounding the rebar.

The solution needs to be battery powered and portable to be feasible for field applications. We are also interested in solutions that can help us determine the rate of corrosion and lifespan of a concrete structure.

Expected Outcomes

The solution assists the inspection and/or monitoring process of the state of rebar or concrete to accurately identify if corrosion has taken place. Repair actions can then be taken to prevent further damage. Such a solution would help to eliminate the time and manpower needed to remove the concrete cover, while maintaining or lowering the total cost of corrosion monitoring.

Download all challenge statements

Learn More

Challenge Owner(s)Chuan Lim Construction
Industry Types(s)Construction

Chuan Lim Construction

The conventional method of installing large Reinforced Concrete (RC) pipes with diameters up to 3m and weigh up to 16 metric tonnes involves a crane, lifting equipment, and a team of more than 8 workers with the relevant expertise to execute the work over 6 to 8 hours. The work is manual and poses safety risks, such as lifting equipment failures and pinch points. These RC pipes are installed in open trenches about 6m deep and will become part of the sewer and water infrastructure.

To improve productivity, a new mechanical system that uses hydraulics to pull the RC pipes along the sleepers has been developed and has shown successful results by increasing the number of pipes laid per day from 1 to 4. The operating procedure for the mechanical system can be found in the Resources section.

Opportunity Areas and Key Challenges

The mechanical system could become smarter by incorporating sensors and/or IoT systems. One of the challenges faced is that the system needs to be accurately operated as the pipe reaches its final position to connect with another pipe. If force is overexerted, one or both pipes could be damaged, and would need to be reworked or replaced. The operator currently relies on the banksman to provide accurate information and instructions to act on.

We seek a sensor and/or IoT system that can improve the mechanical system or the pipe installation process in at least one of the following ways:

● Provide real-time and precise information or alerts on the position of the pipe to the operator;

● Simplify or automate the operation of the mechanical system to manoeuvre the pipe into its final position; and/or

● Track the performance of the mechanical system and its operation, and analyse the data to improve the entire pipe installation process.

Expected Outcomes

The solution works in tandem with the mechanical system to assist with the RC pipe installation
process. The system reduces the total time taken to install an RC pipe by 20% (or one additional

pipe installed per day) and decreases the manpower required in the process by at least one person.

Download all challenge statements

Learn More

Challenge Owner(s)Tiong Seng Construction
Industry Types(s)
Construction, ICT and Media

Tiong Seng Construction

Building designs are constrained by factors such as cost, time and challenges faced during the production process, but never imagination. The benefits of utilising 3D printing in construction provides breakthrough opportunities in various parts of a building such as its facade, allowing for a unique look and therefore potentially increasing the value of the building.

Bespoke and complex facades can be made sustainable with 3D printing. It unleashes the potential of fascinating designs while reduces reliance of laborious production processes from the likes of craftsmen.

Opportunities Areas and Key Challenges

3D printing is recognised as a technology that can enable the sustainable development of bespoke building components. The following should be considered for the solution to be feasible:

  1. The solution should be able to produce aesthetically pleasing and boundary pushing designs to derive products that include free form and non-symmetrical components.
  2. The solution must be scalable to cater for larger-scale production of building components.
  3. The material used for 3D printing must be environmentally sustainable and preferably recyclable.
  4. The solution should be cost-effective, especially if the production is scaled.

We are looking for solution provider(s) with the ability to both generate complex designs of building components using computational methods, and provide the 3D printing technology to their designs.

The solution provider must have strong 3D printing and post-processing capabilities to produce high-quality building components in accordance to its designs. The Challenge Statement Owner will be able to support the solution provider with engineering expertise and insights into the site assembly process.

Expected Outcomes

The 3D design and printing services enable the construction of building components, particularly facades that are aesthetically impressive. As part of the prototyping process, the solution provider will produce computational designs of facades and physical samples (in the range of 300mm x 300mm to 500mm x 500mm) based on the computational design. The solution must cater for large-scale production and consider factors like cost and sustainability.

Additional Information Required

As part of your submission, you should include computational design examples of facades that you can generate and/or photographic examples of complex 3D models that you have previously produced.

Download all challenge statements

Learn More

Challenge Owner(s)Teambuild Construction Group
Industry Types(s)
Construction, Land Transport, Logistics

Download all challenge statements

Learn More

Challenge Owner(s)Teambuild Construction Group
Industry Types(s)Construction

Download all challenge statements

Learn More

Challenge Owner(s)Housing & Development Board (HDB)
Industry Types(s)
ICT and Media, Real Estate

Housing & Development Board (HDB)

Before renovating a Housing Development Board (HDB) property, the applicant is required to submit the proposed Addition and Alteration (A&A) work plan to HDB to request for approval. The HDB personnel will review the A&A work plan to ensure the works will not affect the building structures before granting approval.

This is a tedious and time-consuming process, and involves searching for the relevant building plan drawings specific to the housing project found in HDB’s databases.

What We Are Looking For

HDB receives more than 2,000 A&A applications monthly. The current workflow to process plan submissions can be streamlined and automated to save significant time for HDB personnel.

An intelligent knowledge base could be deployed to automatically execute the task of
searching through several databases to retrieve the relevant drawings and then automatically
mapped and identified the proposed work in relation to the building structures. The HDB
personnel involved can then easily navigate between the relevant drawings in the knowledge
base. For example, the HDB personnel is able to access the drawings by clicking on the
drawing names found under the “List of Drawings” document, then mapped the submitted
A&A work plan against the retrieved drawings from the databases. Concurrently, the process
identifies any non-compliances affecting the building structures.

The proposed solution should also possess the following features and capabilities:



  • Ability to recognise and interpret text and image data found in the PDF drawing files;
  • Provide links to the text and images to access the relevant drawings;
  • Intelligent system to recognise and map the proposed A&A work plan on different sets of building plans and identify non-compliances.
  • A user interface that compiles and displays relevant drawings while allowing annotations; and
  • Ability to generate a supporting report if the proposed A&A work plan submission does not meet the requirements.

Expected Outcomes

The automation solution searches and retrieves relevant drawings from HDB’s databases to support the processing of A&A work plan submissions. The solution streamlines the workflow and saves a significant amount of time and manpower.

Apply Here

Challenge Owner(s)
CSCEC, Greatearth
Industry Types(s)
Construction, ICT and Media

CSCEC, Greatearth

Once precast elements, such as pillars, walls and slabs, have been constructed off-site, they are transported to the site and installed using cranes.

The precasters, site supervisors, and engineers currently rely heavily on verbal communication to plan and coordinate the installation, while referencing 3D or 2D drawings. There is still a disconnect between the digital drawings and the realities at the construction site. This could cause misalignment between the stakeholders which leads to incorrect installations and delays in the project.

Both installation and inspection of precast elements involve a lot of manual work. The installation team uses simple markings and manual measuring methods to determine the position and orientation of the precast elements before the elements (pillars, walls and slabs) are lifted in. After installation, the inspection process would once again require the tedious process of cross-referencing documents and drawings, and using manual measuring methods to audit the accuracy of the installations.

What We Are Looking For

For industrial projects, the number of precast pillars required for installation could amount to thousands. An Augmented Reality (AR) solution that could project the 3D models onto the construction site would help the different stakeholders better visualise the required layout for accurate execution of the precast element installation. Once the installation is done, the AR solution can help the inspector to visualise the installation requirements to verify the accuracy.

For the initial stage of development, our priority is to have the structural elements visualised. But the solution could further expand to mechanical and electrical systems.

The solution needs to be operable from a mobile device or tablet, and could be integrated into the existing Common Data Environment system that is currently used during the inspection process.

Expected Outcomes

The AR solution assists the site stakeholders to visualise and compare the structural installation requirements in 3D. The solution supports better execution of precast element installation.

Apply Here

Challenge Owner(s)
King Hup Construction Pte Ltd, Hong Leong Holdings Limited
Industry Types(s)
Construction, ICT and Media, Logistics

Hong Leong Holdings Limited, King Hup Construction Pte Ltd

For a residential or hospitality construction project, almost every unit needs to be installed with cabinets. On a fortnightly basis, the supervisor will survey the units and manually record down the progress achieved with details on the stage of installation on a paper progress monitoring chart (see Resources for an example of this chart).


The progress monitoring chart is submitted to the contracts department to be digitised. The contracts department then prepares a summary report to the main contractor for progress updates and payment claims. The current process is tedious, time consuming, and prone to human error.

In order for payment to be claimed, both the cabinetry contractor and property developer need to dispatch their quantity surveyor to verify that the reported work has been completed in accordance to specifications and quality standards. The actual claim amount and payment dates are highly dependent on the availability of the quantity surveyor to complete their verification.

The current process to conduct quantity surveying checks is time consuming and needs to be done on-site. If the quantity surveyor only partially completes their verification, a lower claim amount will be issued.

What We Are Looking For

The current progress tracking and quantity surveying process would benefit from digitisation. The contractor would input the data directly into the digital platform to eliminate the need for administrative staff to digitise the paper-based monitoring charts. For good usability, the solution should have customisable forms that can be tailored based on the workflow and stages of installation.

The digital platform would also offer new possibilities to collect and organise new types of data, and enable quantity surveying to be done remotely. The supervisor could upload photos or even videos onto the platform, so that it can be used by quantity surveyors for verification purposes.

A real-time dashboard reporting and visualising work progress for the management would support better manpower and material delivery planning to prevent project delays. The solution should also be able to easily generate a summary report to be shared with external stakeholders, such as the main contractors and property developer.

It is important for the solution to be kept simple and cost effective for adoption by small and medium enterprises. The solution could also be adapted for the following works:

  • Frame and door installation works
  • Aluminium window installation works
  • Wall and floor finishing works

The solution better monitors the progress for cabinet installation through the use of a digital platform and generates reports for internal and external stakeholders. The solution enables better planning of manpower, materials and deliveries. The solution also captures useful data to support remote quantity surveying.

Apply Here

Challenge Owner(s)
Penta-Ocean Construction, SK E&C
Industry Types(s)
Construction, ICT and Media, Professional Services

Penta-Ocean Cosntruction, SK E&C

Construction companies currently use multiple digital platforms to support document management, site management, safety management and project management activities. However, none of the existing digital platforms is able to provide all the features required by these companies.

These platforms are not fully compatible with each other, and this results in data silos and even data loss. The data often needs to be retrieved from the different platforms to generate the reports required by various construction stakeholders.

We are interested in a Common Data Environment (CDE) system that would comprise a single platform or a consortium of integrated platforms to support document management, site management, safety management and project management activities. The data and information are consolidated and accessible throughout the platform(s).



The following are the key features that the platform(s) would ideally have:

​Document management

  • Easy access: Allow for access using web and application-based platforms, as well as offline access for sites with low internet connectivity.
  • Online submission and replies: Allow for online submission and replies of shop drawings, Request For Information (RFI), Submission For Review (SFR), Superintending Officer's Instruction (SOI), and site memos. If a document is pending or overdue for replies, it should be flagged out to the relevant parties.


Site management

  • Inspection management: Allow for an online and paperless inspection and verification process with an in-built e-signature function.
  • Defect management: Allow for the creation of defect lists, the automatic channelling of the defect rectification tasks to relevant parties, and the tracking of the completion of rectification tasks.
  • BIM model viewing: Able to view and comment on BIM models on the platform without the need for a separate authoring software.
  • Report generation: Able to generate reports using the data from the platform in customisable formats to cater to client or consultant’s requirements.

Safety management

  • Permit-to-work management: Allow for online and paperless application and approval process with an in-built e-signature function.
  • Safety event management: Allow for online and paperless documentation of safety events, and tracking for corrective actions.

Project management

  • Subcontractor management: Able to track the activities of subcontractors, identify project delays, and estimate the additional manpower required to keep up with the master timeline.
  • Meeting support: Able to generate useful information to incorporate into meeting agenda and collect meeting minutes.
  • Progress payment management: Able to accurately track progress for payment claims and help management to visualise the cash flow and the project S-curve.

General

  • Cross-platform support: The CDE system can be operated on portable gadgets such as mobile phones and tablets for site staff’s convenience.
  • Email integration: Able to integrate with mail service providers, for example Gmail, to extract and send information seamlessly.
  • Cloud application integration: Able to integrate with cloud applications, such as calendar  and cloud storage.
  • Smart notification: Able to provide timely reminders and status updates.
 Under Resources, a few bonus features were described by SK E&C with the objective of enhancing real-time interconnectivity between the BIM models and site activities.



Expected Outcomes

A more comprehensive CDE with most of the features described above that better supports the stakeholders and thus enables them to be more efficient and effective. If multiple platforms are proposed, the platforms must be designed to be fully compatible with each other.

Apply Here

Challenge Owner(s)CSCEC
Industry Types(s)
Construction, ICT and Media

CSCES

The fabrication of Prefabricated Prefinished Volumetric Construction (PPVC) modules is currently done in dedicated production facilities located in Singapore and Malaysia.

Quality checks are required during the different stages of the fabrication process to ensure that the PPVC modules are constructed accurately based on the required specifications. The following is a non-exhaustive list of examples of checks required for key elements, which are further illustrated in the document found under Resources:

Pre-pour stage

  • Measure the mould size.
  • Verify the size of the rebar and measure the spacing distance.
  • Measure the size of the openings and verify the accuracy of their positions.
  • Verify the size of the electrical conduit and the accuracy of its position.
  • Verify the size of the plumbing pipe and the accuracy of its position.


Post-pour stage

  • Measure the resulting carcass size.
  • Measure the size of the openings and verify the accuracy of their positions.
  • Verify the accuracy of position for mechanical and electrical provisions.

The inspectors currently travel to the site to conduct quality checks on selected activities in the fabrication process. COVID-19 has made it more challenging to conduct these visits. At the fabrication site, the inspectors require the assistance of the workers to make measurements manually using measuring tapes or digital calipers, while they observe and capture photographic evidence for documentation purposes.

What We Are Looking For

We are interested in using imaging and/or LIDAR devices enabled by Artificial Intelligence to support the remote monitoring and inspection of the PPVC fabrication process. This potentially allows the inspectors to cut down on their travelling time and generate better documentation.

Here are some key considerations:

  • The current plan is to have imaging devices that can be mounted on the ceilings. But this might offer limited visibility of the fabrication process. We are interested in exploring different ways of deploying imaging devices.
  • The solution should be capable of accurately measuring the key elements mentioned in the above list of quality checks.
  • The required precision of the measurement varies according to the inspection task. For rebar size, the measurement needs to be in millimeters.
  • As part of the inspection process, the solution should capture photographic evidence intelligently and tag the photos for easy reporting.

Expected Outcomes

The solution enables the remote monitoring and inspection of the PPVC fabrication process by intelligently capturing the measurements of the key elements and documenting the inspection process. The solution minimises the need for the inspectors to travel to site to conduct quality checks.

Apply Here

Challenge Owner(s)
Surbana Jurong, WeWork
Industry Types(s)
Construction, Environmental Services, Real Estate

Surbana Jurong, WeWork

Office spaces, especially those with open concept design, are designed with air conditioning and mechanical ventilation (ACMV) systems that use a blanket approach to regulate the temperature within an area and are not customisable to each occupant’s needs and preferences. The temperature is usually set in the colder range, as it is more widely accepted.

This leads to higher energy consumption to meet the cooling demands. Cooling a typical office space is estimated to account for approximately 60% of the total energy consumption of a building. Thus, an effort to reduce cooling demands by 15-20% would significantly save energy and operating costs.

What We Are Looking For

We are interested in solutions that can provide personalised thermal comfort for the office occupants, while reducing the total energy consumption of the office. Good thermal comfort allows occupants to improve their productivity at work by creating an environment conducive for their well-being and minimising distractions.

The solution should work in tandem or even integrate with the existing ACMV systems in the office to achieve optimal outcomes. For tenants that lease the office spaces, it is desirable that the solution would require minimal modification of the existing ACMV systems.

The following describes how personalised thermal comfort and energy savings could be achieved:

  • The solution monitors the presence and state of the occupants to understand their thermal comfort requirements.
  • The solution allows occupants to personalise settings or provide feedback.
  • The solution can adjust the airflow rate, direction, quality, or moisture levels for the area occupied by an individual.

Expected Outcomes

The solution is scalable office-wide to improve thermal comfort for all occupants at a personal level without sacrificing thermal comfort of their neighbouring occupants. The solution helps companies achieve at least 15% ACMV energy savings in their offices.

Apply Here

Challenge Owner(s)
Hongkong Land, JTC Corporation
Industry Types(s)
Electronics, Environmental Services, Real Estate

Hongkong Land & JTC Corporation

The cleaning of industrial/commercial building façades is done annually and in some cases, half-yearly. The work typically involves a minimum of 3 persons, 2 of whom work at height using a gondola or rope access system, with one safety personnel. The duration needed to complete the cleaning process of a building typically ranges from one to three months.

As part of the process of cleaning, there is further potential for added synergy to also incorporate inspection and repair elements into the gondola or rope access system.

Currently, building façades are required to be inspected on a regular basis . Defects are flagged out by the inspectors and prioritised according to severity for follow-up actions. This challenge seeks to primarily develop an autonomous façade cleaning solution, where integration with automated inspection techniques to guide the system to subsequently perform repair works for minor defects would be an added enhanced feature considered.

What We Are Looking For

An unmanned robotics solution that can replace current manual methods of cleaning, inspecting and repairing can lead to the following benefits:

  • Lower the life cycle cost of the building;
  • Reduce the manpower requirements for façade maintenance;
  • Improve resilience of the building by detecting and repairing building defects early;
  • Reduce the safety risk from working-at-height;
  • Uniform cleaning of building façades to remove human error with results that are highly replicable on other buildings.
Challenge Owner(s)Exceltec
Industry Types(s)
Electronics, Environmental Services, ICT and Media

Exceltec

In order to uphold high hygiene standards for the washrooms in commercial buildings, cleaners are assigned to perform scheduled spot cleaning. A cleaner needs to be deployed for per-demand cleaning every time there is feedback that a toilet’s hygiene is unsatisfactory.


During the scheduled spot or per-demand cleaning, the cleaner will need to perform the following activities:

  • Cubicle door management, able to push open the door and fit into the cubicles;
  • Toilet seat cleaning, for example use of damp cloth or other equipment to clean the toilet seats and damp mop to clean squat toilets
  • Seat cover management;
  • Urinal cleaning;
  • Wash basin wiping;
  • Damp mopping;
  • Completing the task within stipulated timing
The washroom environment is dynamic, and the solution considerations are not limited to the above requirements.

The solution would ideally be able to finish each washroom cleaning session within 15 minutes, so there is minimal downtime.

For a robotics solution to be feasible for usage in a washroom, it should have the following specifications:

  • The solution is battery operated
  • The solution must not have cameras or collect data that compromise personal privacy
  • The solution can navigate within the washroom while toilet is still open for usage and avoid/stop work when human is nearby
  • The solution must not be hazardous to the human operator and passersby
  • Electrical protection (due to damp cleaning)
  • Manageable weight of machine (due to usage by mature worker strength) if solution transportation of the machine to the washroom
  • Sleek/slim design of machine to navigate washroom with people inside (due to toilet layout; tight space)

What We Are Looking For

A robotic solution that performs a good portion of the cleaning activities currently being done by human cleaners could make the cleaning much less labour intensive. In terms of priority, the robotics solution should minimally be able to clean washroom cubicles based on the following requirements:

  • Able to push open the door and fit into the cubicles;
  • Able to spray cleaning liquids on the required surfaces; and
  • Able to use the right tools for the right surfaces, for example, separate the brush used for the toilet bowl and the toilet seat.

The washroom environment is dynamic, and the solution considerations are not limited to the above requirements. For a washroom with a floor space of 12 sqm and two cubicles, the solution would ideally be able to finish each washroom cleaning session within 10 - 15 minutes, so there is minimal downtime.

For a robotics solution to be feasible for usage in a washroom, it should have the following specifications:

  • The solution is battery operated.
  • The solution must not have cameras or collect data that compromise personal privacy.
  • The solution is able to navigate within the washroom with minimal human assistance.
  • The solution must not be hazardous to the human operator and passersby.
We expect the robotics solution would still require human assistance to operate. A cleaner could transport the robot to the start point to commence cleaning, and would inspect the results after cleaning is done.

We are open to retrofitting cleaning mechanisms if the solution is capable of cleaning washrooms with high standards, and is cost effective for the initial setup and maintenance.

Expected Outcome

The robotic solution supports spot cleaning operations by reducing manual labour required and increasing the productivity of the cleaners. The time spent to complete the spot cleaning of one washroom is reduced by 30%.

Apply Here

Challenge Owner(s)
CSCEC, Greatearth
Industry Types(s)
Air Transport, Construction, Electronics, ICT and Media

CSCEC & Greatearth

Photogrammetry is a workflow to convert photographs or videos of physical space into a virtual 2D or 3D model that can be measured and manipulated. Drone photogrammetry is already being conducted on a weekly basis for site monitoring.

The process to produce drone photogrammetry is time consuming and tedious. It takes several days of flying the drone to capture enough input photos.

The flight is semi-automated and still requires a pilot to manage the flight schedule, battery life, and any potential risk to the drone, such as weather.

The data processing currently requires a person to download the data from the drone manually and upload it to the photogrammetry software for processing. Any technical issues are hard to resolve due to the lack of local support.

What We Are Looking For

Drone photogrammetry is already being done, but the current processes could be further improved. We are interested in a solution that can enhance the drone flight operations and reduce the need for human intervention by intelligently managing the flight schedule, battery life, and risks. It is also desirable if the total flight time can be reduced while maintaining high-quality photogrammetry results. If the data processing can be optimised or automated, the photogrammetry results can be produced more seamlessly and relieve the personnel of the routine activity.

​The photogrammetry results would allow site personnel to visualise topographical surveys of the site and compare the results based on the different timestamps. 3D visualisation would be useful to study some key indicators of progress, such as the excavation depth and building height. A web application to display the photogrammetry results is preferred.

The challenge statement owner’s own drones are available for use, but the solution provider could propose its own drone if it supports better integration with the proposed solution.

Expected Outcomes

The solution replaces the existing method to produce drone photogrammetry by enhancing the drone flight operation and data processing, while minimising the need for human intervention.

Apply Here

Challenge Owner(s)CKR Group
Industry Types(s)
Construction, Professional Services, Real Estate

CKR Group

During the design stage of Prefabricated Prefinished Volumetric Construction (PPVC) projects, permutations of unit layout plans are explored manually. Besides fulfilling the architectural vision and requirements, residential unit layout plans seek to maximise the gross floor area and minimise the number of volumetric moulds required.

Volumetric moulds are used to produce the concrete finish of constructed modules. The moulds could cost S$70,000-100,000 and take up to three months to fabricate. If the unit layout plan is optimised to allow for more repeated use of volumetric moulds, significant cost savings can be achieved.

The design stage takes up to six months to complete due to the need to manually explore possible permutations of unit layout plans and iterate the plan between the consultant and contractor.

The following are the steps taken for the design stage of each PPVC project:

  1. The consultant prepares the unit layout plan and passes it to the PPVC specialist contractor for a design study.
  2. The PPVC specialist contractor prepares the building information modelling (BIM) drawings, checks the design, determines mould groupings, and submits a study on the mould requirements, which includes details on how the moulds could be used repeatedly.
  3. The consultant evaluates the mould requirements and revises the unit layout plan to reduce the number of moulds required. The consultant passes the revised plan back to the PPVC specialist contractor to study the mould requirements.

What We Are Looking For

The current methods could be replaced with design simulation tools that can automatically generate permutations of the unit layout plans and support the design feasibility study.

The unit layout plans generated this way could reduce the number of moulds required while maximising the gross floor area.

Based on the plans, the solution would help determine the mould groupings, mould requirements, and the repetitions of each mould.

The proposed solution would create a shared environment for both the consultant and contractors to view, discuss and propose design updates.

Expected Outcomes

The solution generates and evaluates the possible permutations of the unit layout plans to optimise the number of moulds and support the design feasibility study. The solution reduces the time and manpower required for the design stage of PPVC by at least 50%.

Apply Here

Challenge Owner(s)Tiong Seng Construction
Industry Types(s)
Construction, Environmental Services

Tiong Seng Construction

In Singapore, cooling is a major driver of electricity consumption and demand. For example, air conditioning consumes a high percentage of energy in buildings.

Building owners have been trying to implement passive cooling methods that do not consume additional energy, such as tinting windows with heat- and UV-blocking films, to control heat gain and heat dissipation in a building.

What We Are Looking For

For the benefit of environmental sustainability, we are looking for radiative cooling solutions that can be applied to the external surface of a building, such as concrete walls, glass facades and windows. The solution should be most effective during the day, when there are high levels of solar radiation and therefore, greater demand for cooling. Nano-materials are desirable due to their high potential efficiency.

The radiative cooling solution should have the following characteristics:


• Radiates infrared waves from solar radiation to outer space and prevent heat gain in buildings;


• Can be applied on different surfaces (with concrete, steel and glass in particular); and


• Is suitable for tropical climates.


Expected Outcomes

The solution is applied to different surfaces, such as concrete, steel and glass, and reduces heat gain in the building. Importantly, the method used to apply the solution (including the curing process, if needed) must be practical. The cost should also be reasonable.

Apply Here

Challenge Owner(s)City Developments Limited
Industry Types(s)
Construction, Environmental Services, Land Transport

City Developments Limited

In a dense country like Singapore, it is common for residential developments to be located near land traffic noise sources, such as major arterial roads, expressways, and MRT tracks.

Under the National Environmental Agency’s (NEA) guidelines of land traffic Noise Impact Assessment (NIA), the indoor noise level for new residential developments must not exceed 57dBA (Leq 1 hr) under natural ventilation. Natural ventilation has to be provided by means of one or more openable windows or other openings with an aggregate area of not less than 5% of the floor area of the room or space required to be ventilated.

When faced with noise-prone residential developments, developers fulfil the above guidelines in the following ways:

●     Developers adopt layouts that locate facilities such as car parks on plots closest to noise sources, and residential units far away from the noise sources.

●     If the above is not feasible, windows or the glass facade are designed to avoid directly facing the noise sources, and windows facing noise sources are double glazed. Developers will also work with acoustic consultants to establish the minimum size of windows that can meet both the noise and ventilation requirements when opened at 30 degrees, in order to be code compliant.

●     If the above is not sufficient, noise barriers are installed between the transmission path from the noise source to the residential units.

The methods above restrict design and could impact the marketability of the development. If the planned mitigation is found to be insufficient during post-construction testing, developers can only resort to erecting noise barriers at the window area. The noise barriers are often not aesthetically pleasing for potential buyers.

What We Are Looking For

We are interested in solutions that can be used to reduce the noise from land traffic noise sources. The solution could be installed at windows or openings to absorb, deflect or cancel incoming sound waves, while allowing for natural ventilation. It is important that the solution looks aesthetically pleasing, so that it does not deter potential buyers. It is also important that the solution does not completely obstruct the outside view.

If the solution adopts active noise-cancelling technology, it would need to be designed for large-scale integration with the building or compound, and consider long-term sustainability factors, such as power and maintenance requirements.

Expected Outcomes

The solution reduces the noise from land traffic noise sources by at least 10 dBA and keeps indoor noise below the required level of 57 dBA (Leq 1hr), while maintaining good natural ventilation and retaining the marketability of the property. The solution must be suitable for large-scale integration with the building or compound.

Apply Here

Digital Asset Delivery & Management
Tuesday,
19 January 2020

4.00PM – 5.00PM

Advanced Design & Fabrication
Thursday,
21 January 2020

4.00PM – 5.00PM

Building Inspection, Maintenance & Facility Management
Tuesday,
26 January 2020

4.00PM – 5.00PM

Automation & Robotics for Construction
Thursday,
28 January 2020
4.00PM – 5.00PM
